ASMT500R series is a new generation of high-end welding equipment developed by Aotai. It takes an FPGA chip as the control core and adopts a 60kHz inverter main circuit platform as the assistance to increase controlling speed and circuit responding speed several times, achieve the precise control of metal transfer, and bring top-level advanced welding process. All features above make it become the best choice for welding aluminum/carbon steel/galvanized sheet/stainless steel/nickel-based alloy and other materials.
Output
Input
Process
Materials
Share：
FPGA: full-digital multiple-core control system controls the welding process and realizes low-spatter welding precisely
ASMT process: the spatter-free cold metal welding process cooperates with a dynamic wire feeding system to achieve the minimum heat input, down to 0.5mm aluminum alloy, the best bridging capacity (3mm gap), the least welding porosity, and the most outstanding performance and quality
Double-ASMT: the thin sheet welding can also obtain welding seams with perfect ripples
SSAP: super-short arc pulse process, higher welding quality, faster welding speed
CP: constant penetration process, high-quality welds, easier welding at narrow gaps, and fillet welds
CCP: the customer-customized process provides customers with a confidentiality mechanism
Servo motor: full-digital twin-closed-loop raster-feedback wire feeding system, more precise and smoother wire feeding
Digital & DIO interface: abundant configuration solution of robotic peripherals, worry-free connection and matching for robot
1 Power source
1 Connected primary cable L=3m
1 Water cooling machine
1 Ground cable L=3m
1 Water-cooled (or Gas-cooled) torch L=3m
1 Wire feeder with Europe connection
1 Trolley
1 wire feeder cable L=2m
