ATIG-400 /500 /630PAC PLUS is a digital multi-process inverter GTAW machine that can realize MMA, DC CC TIG, DC pulse TIG, AC CC TIG, AC PULSE TIG, and other processes. AC MMA function is the standard configuration, applicable for welding 9Ni steel, LNG tank, and ship body. ATIG-400PAC plus is used for high-quality welding of various materials, such as carbon steel, stainless steel, aluminum and Al-Mg alloy, copper, titanium, and others.
Output
Input
Materials
Share：
High-speed MCD: 60kHz high-frequency IGBT soft switch inverter technology, speedy responding, high arc stiffness
High performance: ARM32 processor, robust computing capacity and expansion interfaces
High reliability: semi-independent wind channel structure, IP23 design, multiple insulations and protections
Low noise: fine control of waveform, lowered noise of AC welding
Wide adaptability: the current through the zero point can be adjusted, applicable for occasions with different requirements for welding penetration or noise
Long cable: The output cable for the DC TIG process can reach up to 50 meters
7-in-1 welding body: AC TIG, AC PULSE TIG, DC TIG, DC PULSE TIG, DC MMA, AC MMA, Cold TIG
Multiple operation modes: 2-step, 4-step, repeat, and spot welding functions for the TIG process
High frequency: a maximum pulse frequency of 500Hz, improved welding penetration
Optional multiple control interfaces: analog remote control, digital remote control, 485 control;
ECO design: lower open circuit lose
Save and recall: capable of saving 100 sets of parameters
Timer function: accumulated working hours
